WAW-2000Y (2000kN) Computer Control Electric-Hydraulic Servo Universal Testing Instrument/Equipment/Machine

WAW-2000Y (2000kN) Computer Control Electric-Hydraulic Servo Universal Testing Instrument/Equipment/Machine

WAW-2000Y (2000kN)Computer Control Electric-Hydraulic Servo Universal Testing Instrument/Equipment/Machine WAW-2000Y (20;
Basic Info
Model NO. WAW-2000Y
Max Diameter of Workpiece 70mm
Type Universal Testing Machine
Maxcapacity 2000kN
Accuracy Grade 0.5
Load Way Mechanical Load
Loading Method Static Load
Display Computer Control and Display
Control Computer Control
Weight 10000kg
Power Source AC380V
Oil Cylinder Position Under
Power Hydraulic
Control Method Automatic Computer Control
Usage Tensile Testing Machine
Brand Name Sida/Star
Measure Range 2%-100%FS
Capacity 2000kN
Grade 0.5
Software English Software and Control System
Model WAW-2000Y
Feature Plug and Play, Simple to Operate
Transport Package Standard Export Plywood Packing
Trademark SIDA/Star
Origin Jinan, China
Production Capacity 200 Sets/Year
Product Description
WAW-2000Y (2000kN)Computer Control Electric-Hydraulic Servo Universal Testing Instrument/Equipment/Machine WAW-2000Y (2000kN)Computer Control Electric-Hydraulic Servo Universal Testing Instrument/Equipment/Machine adopts cylinder down-set and six-column mainframe, which is mainly used for metal and non-metal tensile, compression, bending and shear tests. It is applicable to metallurgy, construction, light industry, aviation, aerospace, materials, colleges and universities, scientific research units and other fields. The test operation and data processing meet the requirements tensile test method for metal materials at room.Standards:
WAW-2000Y (2000kN)Computer Control Electric-Hydraulic Servo Universal Testing Instrument/Equipment/Machine can meet standards ASTM, DIN, ISO, GB and so on.

Main Technical Specifications:
ModelWAW-2000Y
Max Load Capacity 2000kN
Host Machine StructureFour-column & Two-lead screw
Range of Testing Force2%-100% of max load
Load Accuracy±0.5%
Displacement Measuring Resolution0.001mm
Accuracy of Deformation±0.5%
Test range2%-100%FS
Max Tensile Space 800mm
Max Compression Space700mm
Effective Test Width660mm
Piston Stroke250mm
Clamping Diameter of Round SpecimenΦ15-Φ70mm
Clamping Thickness of Flat Specimen0-70mm
Compression Plate Size204*204mm
Piston speed: 100 mm/min
Bending Support Roller Distance450mm
Bending Support Roller Width140mm
Support Point Diameter40mm
Jaw clamping methodHydraulic automatic clamping
Control ModeDisplacement Control, Load Control, Deformation Control
Power Supply3phs, 380V, 50Hz
Net Weight10000kg
